Design / Custom Made Optical Glass Prism Ladder Type Prism K9 AL+AF Coating Beam Splitter Prism
-
High Light
entrance prism
,groove prism
-
Product NameLadder Type Prism
-
Production Modenal Tolerance (mm)Design / Custom Made OEM / ODM
-
MaterialK9
-
Dimensional (mm)14x12x4.5 -0.1
-
Surface Quality40-20
-
Optical SurfaceRa<0.05um
-
CoatingSpecificationAL+AF @420-700nm RAVG>85%
-
ColorColorless
-
Place of OriginChengdu，China
-
Brand NameVSTAR
-
CertificationROHS/SGS
-
Model NumberVS.OP.GR.008
-
Minimum Order Quantity500-1000PCS
-
PriceNegotiation
-
Packaging DetailsVacuum packing
-
Delivery TimeMold Lead Time: 25-60 days /Product Delivery Time:30days after received payment
-
Payment TermsT/T
-
Supply Ability150000Pcs/order/30days
Design / Custom Made Optical Glass Prism Ladder Type Prism K9 AL+AF Coating Beam Splitter Prism
Design / Custom Made Optical Glass Prism Ladder Type Prism K9 AL+AF Coating Beam Splitter Prism
Company Services:
Specializing in the production of various optical components. Aspheric optical glass light components,prism,lens,dome cover,perforated special shaped parts.precision mold lens,etc.our raw material including colored glass quarts,rare earth.etc..
1.Products introduction: This glass prism used for refractor index measuring.
2.Temperature tolerance:-40°+300°.
3.Application area:Foods,fruits,drinks etc.and industry liquid measuring online.
4.Production process:Glass working/molding glass working
Product Parameter
| Material | K9 |
| Color | Colorless |
| Length (mm) | 14.0 |
| Width (mm) | 12.0 |
| Dimensional Tolerance (mm) | -0.1 |
| Thickness (mm) | 4.5 |
| Thickness Tolerance (mm) | ±0.05 |
| Angle Tolerance (°) | ±0.1 |
| Optical surface | Ra<0.05um |
| Surface Quality | 40-20 |
| Coating Specification | @420-700nm RAVG>85% |
| Coating | AL+AF |
| ROHS | Compliant |
Detailed Images
